Keysight / Agilent 16750B 400 MHz State / 2 GHz Time Zoom 4 MSa Analyzer Module
Configuration:
• Data Channels: 64
• Clock/Data Channels: 4
...
• Memory Depth per Channel: 4 Mb

Part Number: 16750-66504

Keysight / Agilent 16534A 2 GSa/s 2-Channel, 500 MHz BW Digitizing Oscilloscope Module
This unit features a standalone scope with many channels and can capture up to 32K on each of eight analog channels simultaneously (single time base). The 16534A allows measuring of slow and fast... events with additional oscilloscope modules to create a multiple time base digitizing oscilloscope and for large channel count measurements, it is possible to configure as many as 20 scope channels in a single system. It is possible to combine the scope with other logic analysis modules and one can arm or trigger the oscilloscope from any module in the logic analysis system to capture and display the analog events that affect your digital system. With the 16534A, one will save time with Autoscale, Auto-Measure, Voltage and Time Markers, and Colors. Autoscale features automatic adjustments for the time, voltage and trigger levels instantly for a stable display of waveforms.

Agilent 16534A Programmers Manual (pdf)
Agilent 16534A Help Volume (pdf)

Tektronix TLA7M4 136-Ch Logic Analyzer Timing Card
This Tektronix TLA7M4 136 Ch Logic Analyzer Timing Card is used and in excellent condition. This sale is for the module only; it requires a Tektronix TLA7xx mainframe and probes to become part of a... fully functional instrument.

Options: 1S - Upgrades 100MHz State to 200 MHz State Timing

Tektronix TLA7LA 2GHz Timing, 136 Channel Logic Analyzer Module
This Tektronix TLA7LA Logic Analyzer Module is used and in excellent condition.

Options: STD: 2GHz Timing, 100MHz State, 32K Depth
Keysight / Agilent 1662CS Logic Analyzer / Oscilloscope
This Agilent / HP 1662CS Logic Analyzer / Oscilloscope is used and in excellent condition. This unit includes a standard BNC probe, a Tek P6137 10 MΩ 10.8 pF probe, a power cable, a printer... connections, and an RS-232 terminator.

Configuration:

• State and Timing Channels: 68
• State Speed: 100 MHz
• Timing Speed: 500 MHz
• 2 Channels of 1 GS/s Single Shot Oscilloscope
• Symbol Utility

Tektronix TLA704 Logic Analyzer Color Portable Mainframe
This Tektronix TLA704 Logic Analyzer Color Portable Mainframe is used and in excellent condition.

Configuration:
• Pentium 133 MHz
...
• 16meg DRAM
• 1.4Gb Hard Drive
• Windows 95 Software
• Tek TLA 700 Application Software V2.0.170
• Digisoft QAPlus V7.1 Application Software
• Mouse and Printer cable
• Installation Manual and User Manual

The software listed above is loaded onto the system and does not include the CD media. This system's hardware and software configuration is preserved as it was originally used. It will be the end user's responsibility to comply with any non-transferable software licensing issues and delete any software that is deemed non-transferable. Upon request, we can delete and format the hard drive prior to shipping for a $20 fee.

Tektronix TLA621 34 Channel Logic Analyzer
This Tektronix TLA621 34 Channel Logic Analyzer is used and in excellent condition.

Configuration:
• 256 MB DRAM / 20.0 GB HDD
...
• 1 Meg Depth at 100 MHz
• Windows 2000 Pro Software
• Tek Application Software V4.2
• No PC Cards Installed (Sold Separately)
• USB and SVGA Ports
• Floppy Drive and CD-Rom Drive
• Type 2 and Type 3 PC Card Slot
• Probes Sold Separately

The software listed above is loaded onto the system and does not include the CD media. This system's hardware and software configuration is preserved as it was originally used. It will be the end user's responsibility to comply with any non-transferable software licensing issues and delete any software that is deemed non-transferable. Upon request, we can delete and format the hard drive prior to shipping for a $20 fee.

Curtiss-Wright / VMETRO / Micro Memory MM-6490DR High Speed, Dual-Port 2GB VME / VME64 / RACEway Buffer Memory
This Curtiss-Wright / VMETRO / Micro Memory MM-6490DR High Speed, Dual-Port 2GB VME / VME64 / RACEway Buffer Memory is used and in excellent condition.

Configuration:
• RAM: 2 GB
Keysight / Agilent 16700A Logic Analyzer Mainframe
This unit ships with a 16610A Emulation Module and Four 5346A High Density Probe Adapters.

Option 003:
128 MB System RAM, 4 MB Video...
RAM

Accessories and Installed Modules:
• 16610A Emulation Module
• (4) E5346A High Density Probe Adapter

View Photo of the rear of the unit.

Keysight / Agilent 16702B Logic Analyzer Mainframe
No Pouch included. Please contact the Artisan Sales department if you require specific software versions or hardware configs.

Input Voltage: 100 / 240 VAC
Keysight / Agilent 16530A 2-Channel 400 MSa/s Digitizing Oscilloscope Timebase Module
The 16530A is not a stand-alone card. It requires at least one 16531A to operate. Multiple 16531A cards can be used with a single 16530A.
...

The 16530A provides 2-channels of full featured 400 megasamples/s digitizing oscilloscope analysis. 100MHz bandwidth, single-shot and repetitive. 3.5ns rise time, 6-bit ADC resolution. Automatic para-metric measurements, auto-scale, ECL and TTL presets.

Agilent 16530A Datasheet (pdf)
Agilent 16530 Programmer Manual (pdf)
Agilent 16530A 16531A Catalog (pdf)

Keysight / Agilent 16555A 68-Channel State/Timing Analyzer Module
The HP 16555A offers industry standard state and timing analysis features at an affordable price, along with deep memory needed to capture elusive system crashes. This piece uses a probing scheme... that makes it possible for you to easily interchange probing interconnections whenever your probing needs change.

Configuration:

• Timing-analysis rate: Conventional 250 MHz
• State-analysis rate: 110 MHz
• 68 Channels/card
• 204 Channels/timebase
• 1M Memory depth/channel

Includes:
(2) Agilent / HP 16555-61606 Probe cables (Single-ended Flying Leads not included)

Part Number: 16555-66503

Agilent 16550A/54A/55A/55D/56A/56D Datasheet (pdf)
Agilent 16554A/55A/55D User Manual (pdf)
Agilent 16554A/55A/55D User Rerefence (pdf)
Agilent 16554A/55A/55D Programmers Guide (pdf)

GE Fanuc IC600CB500 Arithmetic Logic Unit
This GE Fanuc IC600CB500 Arithmetic Logic Unit is used and in excellent condition. This unit is missing the faceplate; however, this does not affect its functionality.
...

Part Number: 44A712770-001, IC600CB500A, IC600CB524K

Tektronix TLA7AA4 Logic Analyzer Module
This Tektronix TLA7AA4 Logic Analyzer Module is used and in excellent condition.

Configuration:
• Firmware Version: 4.4
...
• 136 Channels

Installed Option(s):
• Opt CS: 2 Mb Memory Depth at 450 MHz State Speed

Tektronix TLA7Axx Datasheet (pdf)
Tektronix Logic Analyzer Module Reference Manual (pdf)
