Cobham / Aeroflex / IFR 4821-000 RF Circuit Board
This Cobham / Aeroflex / IFR 4821-000 is the MLS-800 Microprocessor Controlled Ground Station Simulator RF Circuit Board.
DME ATS-2000EA Advanced Tactical Agile Communications Test Set
Configuration:
• ATACTS Software Version: 1.9.7
• 6 1/2 Digit High Accuracy Model
(...)
• 200 MHz / 2.5 Gsps High Speed Model

Part Number: G6-02-0100-841

Cobham / Aeroflex 3025 Digital RF Signal Generators
This Aeroflex 3025 Digital RF Signal Generators is used and in excellent condition.

Configuration:
• Frequency Range: 76 MHz to 6 GHz
(...)
• Frequency Settling Time: 250 μs
• Level Range < 3 GHz: -120 to +5dBm
• Level Range > 3 GHz: -120 to 0dBm
• Level Settling Time: < 3 ms below 4.5 GHz, < 4 ms above 4.5 GHz
• Signal Bandwidth: 28 MHz
• Sample Memory: 32 Msamples
• Max Sample Rate: 66 MS/s

Keysight / Agilent 8754A Network Analyzer
This Agilent / HP 8754A Network Analyzer is used and in excellent condition. There are some button caps missing on the front of the unit, but this does not affect functionality.
L-3 / Narda 56 N-Type Coaxial Adapter
Configuration:
• Max. VSWR: 1.25
• Connectors: Male SMA to Male N-Type
Tektronix 119-4471-01 RF Module
This Tektronix 119-4471-01 is the TDC-10 Tunable Down Converter RF Module.

Part Number: V9B1465-00, 671-2587, V9A-1545-00, 671-2700-01
Bird Electronic Corporation / Thruline 43 RF Directional Wattmeter
This The Bird Electric Corporation / Thruline Model 43 RF Directional Wattmeter is used and in excellent condition. This model does not include the plug-in elements.

Keysight / Agilent 44476B Microwave Relay Driver
This module has (2) 8762A Coaxial Switches installed.

8762A Coaxial Switch Configuration:
• Frequency: DC to 4 GHz
(...)
• Ports: 3
Keysight / Agilent 8595E Spectrum Analyzer
This Agilent / HP 8595E Spectrum Analyzer is used and in excellent condition. This unit has an oven. There is an internal battery that is used.

Configuration:
(...)
• Rackmount Ready
• Spectrum Analyzer Frequency Range: 9 kHz to 6.5 GHz

Options:
• Option 004: Precision Frequency Reference
• Option 041: HP-IB and Parallel Interface

Carlisle / Specialty Connector 5299CC SMA Male to Female Straight Adapter (Lot of 5)
Configuration:

Material
 • Body & Nut: 303 SST Per ASTM A-582
 • Contact: BeCu Alloy Per ASTM B-196
(...)
• Insulator: Teflon Per ASTM D-1710
 • Captivating Epoxy: Sigma VF Type HV
 • Conductive Epoxy: Ablebond 16-1
Finish
 • Body & Nut: Gold Plate Per ASTM B-488 Over Nickel Plate Per AMS-QQ-N-290
 • Contact: Gold Plate Per ASTM B-488 Over Nickel Plate Per AMS-QQ-N-290
 • Insulator & Epoxies: None

Tektronix / Picosecond Pulse Labs 5915-7.46GHz Low-Pass Risetime Filter
Configuration:
• Mounting Plate: Yes
• Input: SMA Jack
• Output: SMA Jack

Part Number: 5915-100-7.46
Pickering 20-525-902-LS1 High Isolation RF Switching Matrix
This Pickering 20-525-902-LS1 High Isolation RF Switching Matrix is used and in excellent condition.

Part Number: 20-525-902-LS1
(...)

• 8x8 Standard Matrix
• 2-Pole Format
• 100Ω Bantam Loop Thru
• 50MHz Bandwidth
• On-Board Isolation Switches
• All Cross Points May Be Connected

System 20 High Isolation RF Matrix Modules are intended for easy construction of high performance matrix switching systems; modules may be simply cascaded to form matrices of almost any size. The unit's built-in self-test gives complete switch confidence.

Pickering 20-525 Datasheet (pdf)
Pickering 20-525 Manual (pdf)
