Features:
- Packet or Cell BER Testing
- DC to 200 Mbits/s Data Rate, NRZ-1
- 256 Kbits Programmable WORD, PRBS, 1's Density and Selectable Mixed Mode
- Auto Search and Auto Sync Capability
- Controllable Gapped Tx Clock
The Tektronix packetBERT PB200 Transceiver Bit Error Rate Test Set is particularly suited to packet-based systems. It's ideal for component or sub-system development testing of TDMA, B-ISDN, FITL, ATM, Satellite modems and similar communications protocols.
The ability to generate a "Mixed Mode" data pattern allows flexibility in constructing many forms of test signals. Two separate programmable word memories of 16 to 256 Kbits in length allow the construction of a packet or cell that can consist of user-definable preamble, overhead and data. The PB200 data generator has one word memory that is used to define the overhead and preamble and a second word memory to define the data. Each memory can consist of a user-defined pattern or PRBS. The PB200 can also function as a fully featured non-packetized BERT.
For complete flexibility in signal analysis, the PB200 allows BER analysis on all, or only part, of the received digital information. Analysis can be performed on only the overhead, only the data or both overhead and data at the user's selection.
The PB200 provides several unique features and capabilities that are not found on other BERT products in this class. The receiver has a clock/data deskew range of 32 ns and the ability to measure propagation delay. Along with the Auto Search setup capability, the receiver can automatically measure "eye-width" at user-selectable BERs and extrapolate BER from data accumulated over much shorter elapsed times than normally required. The transmitter can also generate a gapped clock.
The 9608-0804 Tektronix TJ-16 Receiver Board may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
no_ai_desc
Tektronix 9608-0804 TJ-16 Receiver Board Specs
| General |
| Manufacturer | Tektronix / Microwave Logic |
| Model | 9608-0804 |
| Condition | Used and in Excellent Condition |
| Product Family | PB200, PB-200, PB 200 |
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Artisan Scientific Corporation dba Artisan Technology Group is not affiliated with or a distributor for Tektronix. The depiction, description, or sale of products featuring names, trademarks, brands, and logos is for identification and/or reference purposes only and does not indicate any affiliation with or authorization by any rights holder.
