Features:
- Modular Flexibility
- Reliable Accuracy, Versatility and Strength
- Rugged and Precise
- Quick and Accurate Positioning
The Parker 400XR Series of linear tables allows each unit to be easily configured to meet unique requirements, from
the very basic to the highly complex. Field upgrades and redesigns are easily accommodated. This compatible
family of positioners offers reliable accuracy, versatility and strength. Adapters and brackets make it
easy to combine 404XR and 406XR positioners, as required, to form multi-axis systems without special
design or manufacturing. The 400XR family of products are rugged enough to perform well in the
industrial automation environment (automotive, packaging) and yet they're precise enough to excel in
the high end semi-conductor and instrumentation markets.
401XR / 402XR Positioners
The 401XR and 402XR Series positioners enhance the
400XR family of precision linear positioners, addressing
applications which involve precise positioning of smalle
payloads within a very small space envelope.
These ballscrew driven positioners were developed to
address the needs of industries such as photonics, life
sciences, semiconductor, and instrumentation, where
technology advancements dictate miniaturization of work
envelopes.
404XR Positioners
The 404XR is a sleek compact positioner (47.3 x 95 mm) capable of carrying relatively high loads up to
a distance of 600 mm. Its quick and accurate positioning capability can be attributed to a high strength
extruded housing, square rail ball bearing system, and precision ground ballscrew drive. With its low
profile design, the 404XR is ideal for space restricted applications and its light weight construction
makes it well suited for multi-axis systems.
406XR Positioners
The 406XR is the rugged big brother of the 404XR Series. It can position greater loads (up to 630 kgf)
over longer (2 meters) travels. Because of its size and strength (28 kg-m, 200 lb-ft. moment load
capacity) this durable table is ideal as the base unit in a multi-axis system. From high resolution to high
throughput, selectable ballscrew leads (5, 10, 20, 25 mm) make the desired resolution/velocity ratio
easy to achieve, and stainless steel seal strips alleviate environmental concerns.
412XR Positioners
The 412XR is a rugged heavy duty linear table (285 mm
x 105 mm profle) that enables massive loads (up to
1470 kgf) to be precisely positioned over distances up to
two meters.
