Features:
- 5V and 3.3V Signalling Voltage (VIO) Supported
- 5V Only Power Supply
- 33MHz PCI Data Bus
The AcQuisition Technology i3002 Series M-Module Carrier for 3U cPCI provides a high-performance CompactPCI bus gateway to the M-module interface. The
i3002 has a 3U form factor. Two M-modules can be mounted on the i3002. The M-module interface
of the i3002 complies with the M-module specification. The M-module interface feature A8, A24, D16
and D32 access types.
he PCI interface is PCI Specification 2.2 Compliant, slave only. The PCI to M-module bridge is
implemented by using the PCI9030 PCI Bus Target Interface Chip by PLX Technology Inc.
The i3002 AcQuisition Technology M-Module Carrier for 3U cPCI may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
Functions
Supports integration of M-Module mezzanine cards into 3U CompactPCI systems, enabling modular expansion of measurement, control, or signal processing functionalities; interfaces with the CompactPCI backplane via 32-bit/33 MHz bus for data communication; provides electrical and mechanical compatibility between diverse M-Modules and the 3U cPCI platform; typically used in embedded instrumentation and industrial automation systems requiring flexible modular instrumentation integration.
Platforms
The M-Module carrier board integrates two industry-standard M-Modules into a 3U CompactPCI system architecture. It serves as an interface bridge enabling M-Module peripherals to communicate with cPCI bus controllers, providing a versatile expansion solution for embedded systems. Accommodating two M-Modules simultaneously, it supports various I/O functionalities including analog, digital, communication, and motion control modules. The carrier features A08/A24 addressing. Designed for industrial environments, it operates across extended temperature ranges and withstands shock and vibration, making it suitable for telecommunications, military, aerospace, and factory automation applications.
Applications
Designed to host multiple M-Module mezzanine cards within a 3U CompactPCI chassis, enabling integration of modular I/O functions such as analog and digital signal acquisition, communication, and control. Interfaces with CompactPCI backplanes via standardized connectors for high-speed data transfer and synchronization. Commonly used in embedded test systems, industrial automation, and military/aerospace data acquisition environments requiring flexible, rugged, and scalable multi-channel I/O solutions.
This section includes content generated with the assistance of artificial intelligence (AI) tools. AI is used to increase efficiency and provide timely information. Please note that the content may not have been reviewed for accuracy or completeness. Use this information at your own discretion, and verify details independently as needed.
AcQuisition Technology i3002 M-Module Carrier for 3U cPCI Specs
