Features:
- Measurements From 25 to 1500 Megacycles
- Reduced Accuracy Above 1000 Megacycles
- Can Measure on Active and Passive Elements
The IET 1607-A Transfer-Function and Immittance Bridge is a null-type instrument designed for the measurement of transadmittance, transimpedance, transfer current ratio, transfer voltage ratio, input and output impedance, input and output admittance, hybrid parameters, reflection coefficient, and standing-wave ratio from 25 to 1500 megacycles, with reduced accuracy above 1000 megacycles. Measurements can be made on active as well as passive elements, such as vacuum tubes and transistors. The uses of the instrument may be roughly divided into transfer-function and immittance measurements. A separate indicator unit is supplied for each of these two broad classifications, and scales are calibrated in normalized numbers since they are called on to indicate various units.
With the Transfer-Function Indicator in place, the instrument will measure transadmittance, transimpedance, transfer current ratio, and transfer voltage ratio. It will also measure the direct (ungrounded) impedance or admittance of components by treating them as three-terminal networks.
With the Immittance Indicator in place, the instrument will measure the input or output impedance or admittance of four-terminal networks with the network terminated in either a short or open circuit. It will also measure the two-terminal (grounded) admittance or impedance of components and the reflection coefficient and VSWR of antennas and transmission lines.
The basic functional components of the 1607-A Transfer-Function and Immittance Bridge are: a junction block to which are connected standards and adjustable lines, an indicator assembly with coupling loops and balancing controls, and two adjustable, trombone-type coaxial lines.
The IET 1607-A Transfer-Function and Immittance Bridge may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
Functions
Measures complex transfer functions and immittance of active and passive networks from 25 MHz to 1.5 GHz. Determines complex voltage ratios, transimpedance, and transadmittance for two-port, three-port, and four-terminal devices. Operates as a null-type bridge instrument to characterize network parameters such as forward and reverse gain, input/output impedance, and admittance. Requires an external signal generator and detector for operation.
Platforms
Impedance measurement platform designed for precision laboratory characterization of transfer functions, impedance, admittance, and immittance parameters. Operates within electrical test benches, requiring external signal sources and detectors. Connects via specialized terminals to device under test and external instruments. Used for analyzing complex electrical networks, transformers, filters, and two-port networks. Features multiple measurement modes with selectable test configurations for various parameters. Provides direct reading of parameters through calibrated dials and precision components. Supports detailed analysis of passive components and networks in research and development environments.
Applications
Applications include precision measurement of electrical network parameters such as impedance, admittance, and transfer functions in laboratory and industrial calibration environments; interfacing with test fixtures and signal sources via coaxial connectors; enabling analysis of passive components, filters, and transducers across audio to radio frequencies; and supporting characterization of material properties and circuit elements with high accuracy and repeatability.
This section includes content generated with the assistance of artificial intelligence (AI) tools. AI is used to increase efficiency and provide timely information. Please note that the content may not have been reviewed for accuracy or completeness. Use this information at your own discretion, and verify details independently as needed.
IET 1607-A Transfer-Function and Immittance Bridge Specs
| General |
| Manufacturer | IET / General Radio |
| Model | 1607-A |
| Condition | Used and in Excellent Condition |
| Product Family | 1607-A |
