More Information
Features:
- 0° Illumination/45° Detection
- Measures and Accounts for Variations in Textures and Finishes
- 'Sees' Color the way the Eye Does
- 44mm (1.75 inch) Reflectance Port
- Internal Xenon Lamp Never Needs Replacement
- Automatic Reference Standardization
- Compact, Noiseless, Low Maintenance
Now there's a whole new dimension in the way you'll look at measuring samples. The LabScan XE spectrophotometer takes color measurement to a new and totally different level of sophistication, with more simplicity, more automated features and more versatility than any other product available on the market today. From powders, solids and liquids, to pellets, chips, yarn or paper, LabScan XE is the cutting-edge solution for a host of color measurement applications in plastics, textiles, paint, food, paper, chemicals, pharmaceuticals and building materials.
0°/45° optical geometry, for a better perspective on "seeing" color.
The same color, when seen on surfaces that differ by gloss or texture, ends up "looking" like
a different color to the human eye. LabScan XE's 0°/45° circumferential geometry incorporates a
15-station, fiber-optic ring that collects and averages reflected light from all the stations. The result is a fast, simplified measurement that automatically accounts for the effects of variations in textures, finishes or granulations.
The D07-1009-950 HunterLab Power Board may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
no_ai_desc
HunterLab D07-1009-950 Power Board Specs
| Optics
|
| Geometry | 0° Illumination, 45° Circumferential Viewing w/ 15 Station Fiberoptic Ring
|
| Illumination | Xenon Flash Lamp Filtered to Approx. CIE D65 Illumination
|
| Lamp Life | 1 Billion Flashes
|
| Monochromator | Diffraction Grating
|
| Detector | 256-Element Silicon Array
|
| Measurement Mode | Reflectance
|
| Spectral Performance
|
| Wavelength Range | 400-700nm
|
| Wavelength Interval | 10nm
|
| Photometric Range | 0-150%
|
| Other Specs
|
| Power Input | 100-240 VAC, 47-63 Hz
|
| Communications Interface | RS-232C Serial DB-9 |
| General |
| Manufacturer | HunterLab |
| Model | D07-1009-950 |
| Condition | Used and in Excellent Condition |
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
