HP E1531A

8-Channel Voltage Output SCP Module

Write your review Stock #: 52336-31

Price	Contact Us
Part Number	E1531A
In Stock	74
Available	Today
Location	Illinois, USA
Ship Weight	1 lbs /ea
Condition	Used and in Excellent Condition
Functionality	Tested
Warranty	1-Year Warranty with 30-Day Return Guarantee

Get Your Personalized Quote Today! Send us your information to receive a customized quote from our dedicated customer service team.

	✗

The E1531A 8-Channel Voltage Output SCP provides eight channels of non-isolated voltage source outputs. Each channel can source ± 16 V at up to 5 mA output current. The output voltage resolution is 16 bits (500 mV). Each output is current-limited to protect it from short circuits.

E1531A Datasheet (pdf)

Brands:
Agilent HP Keysight

Expedited
Shipping Available

Expert
Artisan Support

1-year
Artisan Limited Warranty

Sell your equipment

Close ×

More Information

Features:

Use with E1313/E1413/E1415/E1419/E1422
The E1313 VXI Card Can Take Up to Four SCP Modules
All Other VXI Cards Can Take Up to Eight SCP Modules

Agilent's Signal Conditioning Plug-ons (SCP) Modules can be used for different groups of signals, based on the signal level and characteristics. Each SCP is optimized for different levels, and some of these SCPs have filtering to reduce sensor-based noise. Multiple SCPs can be combined on the Scanning A/D to provide the proper signal conditioning for a wide variety of inputs.

sold all of its SCP modules along with some VXI cards to VXI Technology.

When introduced, SCPs were sold as options to the E1313A and E1413A/B. These option labelings are on older modules, with newer modules designated by a SCP model number. For your convenience, the option numbers and model numbers are both listed in the table.

Signal Conditioning Plug-On Series (SCP Modules) Descriptions
SCP Model Number	HP and Manufacturer Part Number	E1313A and E1413A/B Option	Description
E1501A	E1413-66511 / E1413-63511	011	Direct Input SCP
E1502A	E1413-66512 / E1413-63512	012	Low Pass Filter Input SCP
E1503A	E1413-66513 / E1413-63513	013	Gain/Filter Input SCP
E1504A	E1413-66514 / E1413-63514	014	Breadboard (no tests)
E1505A	E1413-66515 / E1413-63515	015	Current Source SCP
E1506A	E1413-66516 / E1413-63516	016	120 Ω Strain Gage SCP
E1507A	E1413-66517 / E1413-63517	017	350 Ω Strain Gage SCP
E1508A	E1413-66518 / E1413-63518	018	Fixed Gain/Filter Input SCP
E1509A	E1413-66519 / E1413-63519	019	Fixed Gain/Filter Input SCP
E1510A	E1413-66520 / E1413-63520	020	4 Channel Sample & Hold SCP
E1511A	E1413-66521 / E1413-63521	021	4 Channel Transient Strain SCP
E1512A	E1512-66501	None	8 Channel 25 Hz Low Pass SCP
E1513A	E1513-66501	None	Attenuator Input / 16 SCP
E1514A	E1514-66501	None	Iso x1, 4 Channel 10Hz LP SCP
E1515A	E1515-66501	None	Iso x1, 4 Channel 100Hz LP SCP
E1516A	E1516-66501	None	Iso x64, 4 Channel 10Hz LP SCP
E1517A	E1517-66501	None	Iso x64, 4 Channel 100Hz LP SCP
E1518A	E1518-66501	None	Resistance Measurement SCP
E1531A	E1531-66501	None	Voltage Output SCP
E1532A	E1532-66501	None	Current Output SCP
E1533A	E1533-66501	None	Digital Input/Output SCP
E1534A	E1534-66501	None	Freq/Totalize/PWM SCP
E1535A	E1535-66501	None	Watchdog Timer SCP
E1536A	E1536-66501	None	Isolated Digital I/O SCP
E1537A	E1537-66501	None	4 Channel Voltage Output SCP
E1538A	E1538-66501	None	Advanced Frequency/Totalize SCP
E1539A	E1539-66501	None	Strain Measurement SCP

The HP E1531A 8-Channel Voltage Output SCP Module may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).

no_ai_desc

HP E1531A 8-Channel Voltage Output SCP Module Manuals, Datasheets, Drivers, Links

HP E1531A 8-Channel Voltage Output SCP Module Specs

General
Manufacturer	Keysight / Agilent / HP
Model	E1531A
Condition	Used and in Excellent Condition
Product Family	E1501A, E1502A, E1503A, E1504A, E1505A, E1506A, E1507A, E1508A, E1509A, E1510A, E1511A, E1512A, E1513A, E1514A, E1515A, E1516A, E1517A, E1518A, E1531A, E1532A, E1533A, E1534A, E1535A, E1536A, E1537A, E1538A, E1539A, E1413-66511, E1413-66512, E1413-66513, E1413-66514, E1413-66515, E1413-66516, E1413-66517, E1413-66518, E1413-66519, E1413-66520, E1413-66521, E1512-66501, E1513-66501, E1514-66501, E1515-66501, E1516-66501, E1517-66501, E1518-66501, E1531-66501, E1532-66501, E1533-66501, E1534-66501, E1535-66501, E1536-66501, E1537-66501, E1538-66501, E1539-66501
