Features:
- High Density Multiplexer Configurable as 128 Single Ended or 64 Differential Channels
- Eight Scan Groups Configurable as 16 Single Ended or Eight Differential Channels Each
- 200 VDC Switching Voltage Per Channel (GX6264-C)
- 250 VDC Switching Voltage Per Channel (GX6264-I)
- Fast Switching Time with 0.5 A Rating Per Channel
The Geotest GX6264Series 128-Channel Scanner / Multiplexer PXI Cards is a 6U PXI scanner / multiplexer that plugs
directly into an PXI or CompactPCI backplane. The GX6264
provides either differential or single-ended scanning capability,
configurable via software commands or DIP switches.
The GX6264 can operate in three modes: direct switching,
universal bus switching, or combination switching mode. In the
direct mode, the GX6264 can route each scan group directly to a
dedicated bus without routing through additional relays. This
mode is differential only.
The GX6264 includes four universal buses, X0, Y0, X1 and Y1,
which are accessible by each of the eight scanning groups in
universal switching bus mode. Each scan group can be utilized in
either differential or single-ended mode, extending its scanning
and multiplexing capability to sixteen channels per group. Since
the eight scanning groups are independent, they can be used for
either scanning to a direct bus or the universal bus.
In combination switching mode, each scan group may be
individually configured for use with direct or universal busses,
thus allowing multiple configurations.
The GX6264-C Geotest 128-Channel Scanner / Multiplexer PXI Card may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
no_ai_desc
Geotest GX6264-C 128-Channel Scanner / Multiplexer PXI Card Specs
| General |
| Manufacturer | Marvin Test Systems / Geotest |
| Model | GX6264-C |
| Condition | Used and in Excellent Condition |
| Product Family | GX6264, GX6264-C, GX6264-I |
