Features:
- Compact General Purpose Bench Power Supplies
- Dual Output of 0 to ±20 V at 0 to 0.5 Amps
- Single Front Panel Control
The HP 6236A / 6237A Triple Output Power Supplies features compact general purpose bench power supplies that are particularly useful for powering developmental IC circuits, both linear and digital.
The HP 6236A / 6237A Triple Output Power Supplies have a dual output of 0 to ±20 V at 0 to 0.5 Amps. The voltages of two 20-volt outputs are adjusted by a single front panel control and track one another within 1%. the +20V and -20V outputs can also be used in series of a single 0 to 40V 0.5A output. The third output differs in 6236A /6237A and 0 to+6 volts at up to 2.5 amps in the 6236A and 0 to +18 volts at 0 to 1 amp in the 6237A.
All controls, meters and output terminals are located on the front panel. Two single-turn potentiometers control the +6V 9or +18V) and ±20V outputs. A three-position meter switch selects on the supplies for display of its voltage and current on two dual-range meters. The +6V (or +18V) and ±20 V outputs share a common output terminal which is isolated from chassis ground.
All outputs are protected against overload or short circuit damage. The +18V output in the 6237A and the ±20 V outputs in 6236A and 6237A are protected by circuits which limit output current to 110% of its nominal maximum. The overload protection circuit for the +6V output in the 6236A has a current foldback characteristic which reduces the output current as an overload increases until only 1A flows through a short circuit. For this output, the current limit depends on the output terminal voltage varies linearly between 2.75A at 6V and 1A at zero volts.
The HP 6236A Triple Output Power Supply may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
no_ai_desc
HP 6236A Triple Output Power Supply Specs
| General |
| Manufacturer | Keysight / Agilent / HP |
| Model | 6236A |
| Condition | Used and in Good Condition |
| Product Family | 6236A , 6237A |
