HP 83486A

3 GHz Optical / 20 GHz Electrical Module

Write your review Stock #: 92285-1

Price	$2,450.00
Part Number	83486A
In Stock	1
Available	Today
Location	Illinois, USA
Ship Weight	10 lbs /ea
Condition	Used and in Excellent Condition
Functionality	Tested
Warranty	1-Year Warranty with 30-Day Return Guarantee

Brands:
Agilent HP Keysight

Expedited
Shipping Available

Expert
Artisan Support

1-year
Artisan Limited Warranty

Configuration:
• Option: H48: 155/622/2488 Mb/s 4th Order Filters

This instrument includes the standard optical interface (View Photo). The 81000xI Series optical interface connectors are sold separately. They are available for purchase from our website here: (Item #50516).

Sell your equipment

Submit Your Offer, We’re Here to Assist! If we find your offer reasonable our dedicated customer service team will get back to you.

		✗

Close ×

More Information

Features:

Integrated, Calibrated Optical Channel
2.5 GHz Optical Channel Bandwidth and User Selectable 12.4 or 20 GHz Electrical Channel Bandwidth
1000 nm to 1600 nm Wavelength Range
Electrical Measurement Channel

The 83486A 3 GHz Optical / 20 GHz Electrical Module provides measurement channels, including sampling, for the 83480A and 54750A mainframes. The plug-in module scales the input signal, sets the bandwidth of the system, and allows the offset to be adjusted so the signal can be viewed. The output of the plug-in module is an analog signal that is applied to the ADCs on the acquisition boards inside the mainframe. The plug-in module also provides a trigger signal input to the time base/trigger board inside the mainframe.

The HP 83486A 3 GHz Optical / 20 GHz Electrical Module may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).

no_ai_desc

HP 83486A 3 GHz Optical / 20 GHz Electrical Module Manuals, Datasheets, Drivers, Links

HP 83486A 3 GHz Optical / 20 GHz Electrical Module Specs

General
Manufacturer	Keysight / Agilent / HP
Model	83486A
Condition	Used and in Excellent Condition
Product Family	83486A, 83486-A, 83486 A

We know that questions arise, and that sometimes you need more details or a closer look to make the right decision. That’s why we make it easy for you to reach out directly—so you’re never left wondering.

With our team, you’re just a message away from clarity and confidence. Whether you have a specific question, need a particular image, or want more details, the request form puts you in control. Let us know what you need, and we’ll bring the answers straight to you—no guesswork required!

Request Form

Item to Inspect: 92285-1 - HP 83486A 3 GHz Optical / 20 GHz Electrical Module

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Artisan Scientific Corporation dba Artisan Technology Group is not affiliated with or a distributor for HP. The depiction, description, or sale of products featuring names, trademarks, brands, and logos is for identification and/or reference purposes only and does not indicate any affiliation with or authorization by any rights holder.

3 GHz Optical / 20 GHz Electrical Module Price & Specs
