2681 Racal Frequency/Time Interval Counter + Load
Looking for one or multiple units? We'll check our supplier network for availability, condition, price and lead time for you.
This item isn't in our warehouse right now, so it can't ship right away like our in-stock items. We can often source items like this through our industry connections. Request a quote and we'll confirm availability, price, condition and lead time before you commit.
Get Your Personalized Quote Today!
Send us your information to receive a customized quote from our dedicated customer service team.
Item details
| Part Number | 2681 |
|---|---|
| Availability | Not in Stock |
| Location | Champaign, IL USAships worldwide |
| Stock # | 92894-1 |
| Ship Weight | 15 lbs /ea |
| Condition | Used and in Good Condition |
| Warranty | 1-Year Warranty with 30-Day Return Guarantee |
Description
Part Number: 405403-001
Click anywhere or press Esc to close
1 / 42 / 43 / 44 / 4That idle equipment in your warehouse could be cash.
Government & Enterprise Buyers: volume pricing, POs and government purchasing.
Government SalesWrite a Review
Share your experience with this item to help other buyers.
Request More Information
Have a question about this item? Send us a message and a specialist will follow up.
Thank You!
We have received your InstraView Request and will be contacting you shortly.
More Information
Astronics / EADS / Racal 2681 Frequency/Time Interval Counter + Load Overview
Features:
- Meets Requirements for Joint Services Military ATE Programs
- Perform Precision Timing Measurements with Unsurpassed Resolution
- Programmable Load
The 2681 counter offers 200 MHz frequency measurements with up to 9 digits of resolution per second. In Time Interval mode, the resolution is 1 ns in single shot and 100 ps in average mode.
By using Time Error Correction (TEC) in combination with traditional recipromatic techniques, measurement time is minimized without any performance compromise.
Programmable measurement Timeout enables system performance to be optimized where input signals are missing.
The trigger level is programmable from -5.1 V to +5.1 V (-51 V to +51 V in x10 mode) with a resolution of 2.5 mV (25 mV in x10 mode).
The 2681 counter offers independent 50 kHz low pass filters on each channel to allow measurements in noisy environments.
The sensitivity of the counter can be reduced to optimize the front end for low-level or low slew rate signals with noise. This feature is also very important for system applications, where noisy signals are encountered. Four standard sensitivity settings are provided.
Nine different modes are provided with the ability to select the arming source between the external arming input and the VXI TTL trigger lines.
The 2681 counter includes a five-watt programmable resistive load. The load is programmable from 1 Ω to 100 k Ω with 0.1 Ω resolution and provides a stable resistance value under all operating conditions. The load has built-in overcurrent, over-voltage, over-power, and over-temperature protection, which opens the load terminals under any fault condition making it difficult to damage the 2461-LWC2 load.
The 2681 load uses software calibration factors stored in non-volatile memory to maintain its accuracy. Softcal is automated and can be performed by connecting the load terminals to a DMM, but it can also be performed manually
The Racal 2681 Frequency/Time Interval Counter + Load may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
Frequency/Time Interval Counter + Load Price & Specs
Astronics / EADS / Racal 2681 Frequency/Time Interval Counter + Load Manuals, Datasheets, Drivers, Links
Astronics / EADS / Racal 2681 Frequency/Time Interval Counter + Load Specs
| General | |
|---|---|
| Manufacturer | Racal |
| Model | 2681 |
| Condition | Used and in Good Condition |
| Product Family | 2681 |
