Features:
- GigaBerts 1400Rx and 1400Tx
- GigaBert Error Detector / Receiver and Transmitter
- 1400 Mb/s BERT
- Electrical Connection: SMA
The Tektronix GB1400 GigaBERT is a general-purpose 1400 Mb/s bit error rate tester (BERT) built to meet the exacting standards of design engineers who need to verify and characterize high-speed serial data transmission circuits, interfaces and systems. While primarily a lab instrument, the GB1400's compact design, full computer programmability and relatively light weight also enable it to serve in manufacturing ATE and field test applications. The quality of a digital link depends on many factors, but everything comes down to the issue of whether the circuit exhibits a satisfactory BER (bit error rate) and has sufficient margin to function under stress conditions. The GB1400 has all of the features you expect in a general-purpose BERT, and some you expect only in more expensive instruments, such as automated eye-width measurements at a specified BER, and the ability to accept an external real-time data stream for bit error testing.
The GB1400 is focused on the research, design, and manufacturing of telecommunication components, modules, or links operating at data rates to 1400 Mb/s. It is frequently employed in testing and development well under this top speed rating, where sharp clock and data waveforms are especially desired, or where additional frequency range is thought to be needed in the future.
Features:
• Test digital data transmission up to 1400 Mb/s
• Set Data Rate with 1 kHz resolution
• Vary Clock and Data timing with 5 pS resolution
• Phase-Synchronous Clock and Data Edge Tracking
• Measure Eye-Width at Specific BER Automatically
• Auto-Synchronization Rx/Tx Lock-up
• Front panel or computer control operation
Sample Applications:
• Development of Gigabit LAN/Data Comm Devices
• High-Speed Fibre Channel, Ethernet
• Digital Video (MPEG, SDV, HDDV)
• Wideband Satellite Data Links
• SONET/SDH Network Devices up to OC-12e/STM4e
• High-speed GaAs/ECL/E/O device testing
• Test Clock Recovery Circuits
• Parallel-to-Serial Analysis with Tektronix MB100
• Testing of High Speed Fibre Channel links up to 1,063 Mb/s
• Gigabit Ethernet at 1,250 Mb/s.
• Testing of optical busses (Opto Bus, Opto Bahn) at 800 Mb/s per channel.
• Satellite system testing and TDMA (Burst Mode) at 400, 800 Mb/s
• GaAs, ECL and optical component testing
Product Family: GB1400, GB1400T, GB1400R, GB 1400, GB 1400T, GB 1400R, 1400 Analyzer, 1400 Generator, GigaBert1400.
The GB1400 Tektronix GigaBert 1400 Mb/s BERT Generator or Analyzer Repair may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
