2001-12 Tracewell

12-Slot Monolithic Backplane for VME

Write your review Stock #: 56977-12

Price	Contact Us
Part Number	2001-12
In Stock	Limited Availability
Location	Illinois, USA
Ship Weight	11 lbs /ea
Condition	Used and in Excellent Condition
Functionality	Tested
Warranty	1-Year Warranty with 30-Day Return Guarantee

Get Your Personalized Quote Today! Send us your information to receive a customized quote from our dedicated customer service team.

	✗

This Tracewell /2001-12 12-Slot Monolithic Backplane for VME is used and in excellent condition.

Brands:
Compel Tracewell

Expedited
Shipping Available

Expert
Artisan Support

1-year
Artisan Limited Warranty

Sell your equipment

Close ×

More Information

Features:

Patented Open-Frame Design Eliminates Extender Boards
Voltage, Current and Temperature Monitoring
500W Power Supply Provides Up to 80A of 5V
Margin Control for +5V Output Optional
32 & 64-bit Compatible, 12-Slot Auto-Configuring Backplane
Removable Side and Rear Covers Provide Unrestricted Access
Adjustable Fans Reduce Operating Noise

The Tracewell T-Frame for VME /VME64 offers the ideal VME / VME64 test and development platform. The T-Frame for VME / VME64 combines unique design and features into a versatile 12-slot bench-top test system perfect for software and board-level development, manufacturing and test.

T-Frame’s patented open-frame design provides unrestricted access to installed boards, eliminating the need for performance robbing extender cards. Removable translucent side covers protect installed modules, yet easily removes for full access to both sides of installed VME / VME64 modules. A protective rear cover is also removable allowing access to the backplane for probes or additional cabling. T-Frame includes comprehensive monitoring of all backplane voltages, current and exhaust air temperature. A front panel interface displays these monitor outputs and includes temperature, voltage and reset control. The 12-slot backplane provides 32 and 64-bit compatibility, auto-configuration and SMD/press-fit assembly for speed and reliability. An embedded power supply delivers 500 watts with up to 80 amps of 5 volts and features universal input and power factor correction. Fans provide distributed pressurized airflow and adjust from full to half speed to reduce noise. Durable aluminum construction makes T-Frame rugged yet easily portable; perfect for use in remote locations. Other conveniences include a tilt base, removable side and backplane access covers and recessed carrying handles.

Tracewell T-Frame for VME / VME64 combines unmatched utility, performance and innovative design. Versatile enough for any stage from concept through production, the Tracewell T-Frame for VME / VME64 is the perfect tool for any application.

The 2001-12 Tracewell 12-Slot Monolithic Backplane for VME may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).

no_ai_desc

Tracewell 2001-12 12-Slot Monolithic Backplane for VME Manuals, Datasheets, Drivers, Links

Tracewell 2001-12 12-Slot Monolithic Backplane for VME Specs

General
Manufacturer	Tracewell / Compel
Model	2001-12
Condition	Used and in Excellent Condition
