Features:
- High-Speed/High-Accuracy Measurements
- Frequency Range From 5 Hz to 200 MHz
- Discrete Sweep and Limit Lines
The Keysight 3577B Network Analyzer is a high-performance, yet cost-effective, two-channel
network analyzer for use in both research and development and
manufacturing. It is used to measure magnitude/phase, insertion loss,
group delay, SWR, electrical length, and gain compression from 5 Hz
to 200 MHz. When used with the 35676A/B reflection/transmission kit, it can also measure return loss, reflection coefficient, and
impedance.
An optional third channel has been manufactured for use with the 35677A/B
s-parameter test set or for measuring two devices simultaneously.
When used with the 35677A/B, the 3577B can measure all four
s-parameters and any of the parameters listed above without having
to manually alter the test configuration. The 35677A is used for
50 ohm systems and the 35677B is used for 75 ohm systems.
When equipped with optional Instrument BASIC, the
3577B can execute user-written programs designed to automate
measurement systems, compute parameters (such as pass band ripple
and 3 dB bandwidth) or customize the user-interface. This includes
system control of other HP-IB instruments and peripherals, such as
plotters and printers, via the HP-IB. A programmable I/O port,
located on the rear panel, extends Instrument BASIC control to
non-HP-IB devices, such as device handlers, environmental chambers, and even the device-under-test itself.
Of course, the 3577B is fully programmable, either internally
with Instrument BASIC, or externally via the Hewlett-Packard
Interface Bus (HP-IB).
An optional high-stability frequency reference oven has been manufactured for
those users not having an in-house frequency standard.
The 3577B Keysight Network Analyzer may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
