Features:
- PowerPC750 32-Bit Microprocessor
- 32 KB/32 KB L1 Cache
- 1 MB Backside L2 Cache
- 32 MB to 512 MB of On-Board ECC SDRAM
The Motorola MVME2400 series of VME boards provides the performance of Motorola's PowerPlus II Architecture and the ability to be fully customized to satisfy your application needs with two PCI Mezzanine Cards (PMCs). The flexibility of the MVME2400 provides an excellent base platform that can be quickly and easily customized for a variety of industry-specific applications.
Utilizing Motorola's low-power, high-performance PowerPC 750 microprocessors, the Peripheral Component Interconnect (PCI) bus for the on-board peripherals, processor/memory bus to PCI bus bridge, and a VME interface, the MVME2400 processor modules pack optimum levels of flexibility and performance into a single VME slot.
The MVME2432-1 Motorola VME Processor Module may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
Functions
High-performance PowerPC-based single board computer featuring dual 450MHz MPC7447A processors with AltiVec support, up to 1GB DDR SDRAM, 64MB flash memory, dual Gigabit Ethernet controllers, four serial ports, dual PMC sites for expansion, and Universe II VME64x interface supporting 2eSST transfer protocols. Provides real-time processing capabilities for industrial control, data acquisition, telecommunications, military/aerospace applications requiring deterministic performance. Interfaces include GPIO, watchdog timer, real-time clock, and temperature monitoring. Supports VxWorks, Linux, and other real-time operating systems for embedded computing applications in ruggedized environments.
Platforms
High-performance VME processor module featuring dual PowerPC 750 processors operating at up to 450MHz with 1MB L2 cache per processor. Implements VME64 interface supporting A16/A24/A32/A64 addressing modes with D8/D16/D32/D64 data transfers. Includes dual PMC sites, 10/100 Ethernet controller, dual serial ports, and up to 512MB SDRAM. Front panel provides RS-232 debug port and status LEDs. Rear P2 connector supports VSB, geographical addressing, and additional I/O. Operates in 6U VME chassis with standard power supply configurations. Commonly deployed in industrial control systems, telecommunications infrastructure, military/aerospace applications, and real-time data acquisition systems requiring deterministic performance and rugged operation.
Applications
This VMEbus processor module is deployed in mission-critical real-time embedded systems requiring robust deterministic performance. Common applications include industrial automation for process control, SCADA systems, robotics, and complex machine control. It also serves in data acquisition, test and measurement equipment, telecommunications infrastructure, and specific aerospace and defense embedded computing solutions where high reliability and I/O expansion are paramount.
Accessories
Requires VME64x backplane or chassis with 6U form factor support. Needs +5V, +3.3V, ±12V power supply through VME connector. Front panel serial console cable with DB-9 connector required for configuration. Ethernet cable for 10/100Base-T RJ-45 port. VME64x P1/P2 connectors (DIN 41612 type R, 160-pin total) for bus interface. Optional CompactFlash storage card. Heat sink or forced air cooling recommended for thermal management.
Interfaces
VMEbus 64-bit/32-bit backplane interface for system integration; PowerPC 750 333MHz CPU including 32KB instruction + 32KB data L1 caches and 1MB backside L2 cache; 10/100 Mbps Ethernet interface via RJ-45 connector; 32MB ECC SDRAM on-board (expandable to 512MB depending on model); 2MB flash memory; PCI bus interface for on-board peripheral connectivity; asynchronous serial debug port; multiple timer units (four 32-bit, one 16-bit, watchdog timer) for real-time operations; standard VME connectors compliant with IEEE 1014 mechanical spec.
Specifications
VME Processor Module based on PowerPC architecture, integrated with dual PMC slots, 64MB synchronized DRAM expandable to 512MB. Operates within a VMEbus system, supporting real-time processing tasks. Interfaces via Ethernet, serial and parallel ports. Ideal for embedded computing applications in telecommunications, industrial control, and defense systems. Compatible with VxWorks, LynxOS, and Linux OS. Modules connect to backplane via DIN connectors, supporting high data transfer rates and robust I/O capabilities.
