Features:
- Minimum Mode Continually Displays Lowest Thickness Readings
- Handheld and Lightweight (2.1 lb.)
- Few Keys for Simple Operation
- Backlight LCD with Large Numerals
The GE / Panametrics Magna-Mike 8500 Hall Effect Precision Thickness Gage is a handheld thickness gage that utilizes a magnetic method to make reliable and repeatable measurements on nonferrous materials. Operation of the Magna-Mike 8500 is very simple. Measurements are made when its magnetic probe is held on one side of the test material and a small steel target ball is placed on the opposite side. A Hall-effect sensor built in the probe measures the distance between the probe tip and target ball. The measurement is instantly displayed as an easy-to-read digital thickness reading.
The 80TB1 Panametrics 1/16" Magna-Mike Target Balls (Quantity of 188) may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
Functions
Measures thickness using a magnetic probe and a small target ball. Operates within a thickness range of 0.0001-0.0900 inches with a calibrated accuracy of ±3%.
Platforms
Target ball used with Magna-Mike thickness gauges for measuring thin materials, enhancing accuracy and repeatability. Spherical shape ensures consistent contact. Constructed from steel for magnetic attraction. Diameter 1/16 inch, compatible with specific gauge models. Applications include measuring non-ferrous materials like plastics and composites.
Applications
Small spherical magnetic target component designed for ultrasonic thickness measurement systems operating on ferromagnetic materials. Features 1/16 inch diameter with measurement range capability from 0.0001 to 0.0900 inches thickness with ±3% calibrated accuracy. Magnetically couples to probe assemblies for non-destructive testing applications on thin-walled structures, coatings, and material layers where conventional contact methods are impractical or impossible to implement.
This section includes content generated with the assistance of artificial intelligence (AI) tools. AI is used to increase efficiency and provide timely information. Please note that the content may not have been reviewed for accuracy or completeness. Use this information at your own discretion, and verify details independently as needed.
Panametrics 80TB1 1/16" Magna-Mike Target Balls (Quantity of 188) Specs
| General |
| Manufacturer | Baker Hughes / Panametrics |
| Model | 80TB1 |
| Condition | Used and in Excellent Condition |
| Product Family | Magna-Mike 8500, Magna-Mike-8500, Magna Mike 8500, 85RPC, 85 RPC, 801PR, 8525F, 85FSW, 80CAL-020, 80CAL-080, 80CAL-240, 80CAL-NIS, 85BAT, 851PC, 851CC, 802PR, 802PR-109, 852CC, 852PC, 85PRT, 80FXV |
