Features:
- 4 ½ Digit LED Display
- Precision, Autozeroing, Factory-Calibrated A/D Converter
- Scientific-Grade Accuracy ± 2 Counts
- Epoxy-Encapsulated, 12-Pin DIP with Built-In Color Filter and Bezel
The Datel DMS-40PC Series Miniature Digital Panel Voltmeters features a 4 ½ digit LED display and are fully self-contained, component-like, plug-in meters that provide scientific-grade accuracy (typically ± 2 counts or ±0.005% of full scale) and outstanding reliability.
Within its miniature (2.17" x 0.92" x 0.56"), epoxy-encapsulated package, each meter contains a precision reference circuit; a high-resolution, autozeroing, factory-calibrated A/D converter; and a large (0.52"/13.2mm), easy-to-read, LED display. LED's are manufactured in red, yellow and green colors. Red LED's are also manufactured in high-intensity or low-power versions.
The versatile design of the DMS-40PC Series assures trouble-free installation and long-term operation. Differential input voltage ranges are +/-2V, +/-20V and +/-200V. Input impedance is a minimum 800kΩ. Non-inverting inputs are overvoltage protected to ±250V, and CMRR is typically 86dB (dc to 60Hz).
The DMS-40PC's epoxy-encapsulated package has an integral bezel and color filter. The moisture and vibration-proof package is extremely rugged and well suited for harsh environments and extended temperatures. Devices are fully specified for 0 to +50°C operation.
The Series operates from a single +5V supply and typically consume 500mW. Low-power models, whose display is just as bright as standard models, typically consume
175mW. DISPLAY TEST and HOLD functions are standard on each meter, and a complete set of BCD outputs are OEM optional for sending data to CPU's or remote displays.
The DMS-40PC-2-RL Datel Miniature Digital Panel Voltmeter may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
