Features:
- Five Power Ranges for up to 5.9 kW of Continuous Power
- Simplified Tuning and Configuration
- Variable Resolution for the Encoder Out as Well as the Command Input
- Wide Range of PWM Frequencies for Linear Motor Support
- Short Circuit Protection, Brownout Protection, Over Temperature Shutdown
- Diagnostic LEDs
The Parker/Gemini GV is a low-cost, compact, digital servo drive. It is available in 6 power levels for producing up to 40 Amps continuous and 100 Amps peak current.
The Gemini GV features the following:
• Torque, velocity, step & direction and CW/CCW modes
• Encoder tracking mode
• Digital notch filters provide the tools to eliminate mechanical resonance
• Sinusoidal commutation with encoder or resolver feedback
• Simplified tuning and configuration
• Variable resolution for encoder signal output as well as the command input
• Wide range of PWM frequencies for linear motor support
• Three input power ranges available: low – 120V, universal – 120/240V, and high – 240V
• Diagnostic LEDs for drive status, firmware download, and optional keep alive mode
The GV6K-L3E / GV6K-L3E-NK Parker Gemini Digital Servo Drive may still be available for purchase and support from Artisan Technology Group beyond End-Of-Life (EOL) by the manufacturer (OEM).
Artisan Scientific Corporation dba Artisan Technology Group is not affiliated with or a distributor for Parker. The depiction, description, or sale of products featuring names, trademarks, brands, and logos is for identification and/or reference purposes only and does not indicate any affiliation with or authorization by any rights holder.
